Shitan Gk 200 Diesel 380v Soil Testing Drilling Machine

Name: Shitan Gk 200 Diesel 380v Soil Testing Drilling Machine
Brand: JINZHOU SHITAN
Price: 1 USD

Shitan Gk 200 Diesel 380v Soil Testing Drilling Machine Manufactures

Brand Name : JINZHOU SHITAN

Model Number : GK-200

Certification : ISO9001

Place of Origin : China

MOQ : 1 set

Price : Negotiation

Payment Terms : T/T, Western Union

Supply Ability : 2000 sets per year

Delivery Time : 7 days

Packaging Details : Standard Export Package

Product name : SHITAN GK 200 Diesel Soil Testing Drilling Machine Core Drill Rig

Hole Diameter : Customized

Drilling Depth : 200 Meters

Voltage : 380v

Rated Boring Diameter : 200m

Power Type : Diesel

Condition : New

Warranty : 1 Year

Weight : 500kg

Diameter : Customized

Application : Water Well Drilling ,Geological Exploration

Contact Now

SHITAN GK 200 Diesel Soil Testing Drilling Machine Core Drill Rig

SHITAN GK 200 Core Drill Rig Introduction

It is widely utilized and featured in high power and hoisting load(2T), large torque transmission, etc. The rotating speed of vertical hexagonal spindle varies between 71r/min-825r/min. It is suited for the geotectonic survey, geological core drilling, small hole drillings for grout, blast and water well in railway, water coservancy, bridge, dam foundation and other constructions

GK 200 Core Drill Rig Technical Data

GK 200 drilling depth	200m
Rated boring diameter	200mm
Vertical shaft rotation speed (4 shifts)	118, 236, 505, 1010.r/min
Vertical shaft max. output torque	1500N*m
Max. hositing weight single line)	17KN
Drilling rod diameter	42mm
Drilling dip angle	90~75°
Drill outside diameter (LBH)	14336971273mm
Drill weight	500kg
Max diameter	300mm

SHITAN GK 200 Core Drill Rig Feature:

1. With hydraulic automaatic feeding device, elevated drilling efficiency.

2. Large torque and drilling diameter.

3. With a spherial jaw holding mechanism and the rod replacement without breakdwn

4. Compact structure, small volume, lightweight, high detachability,

5. Adoping large drive pipe, double guide rod, increase the stability.

FAQ Of SHITAN GK 200 Core Drill Rig

1. What is the advantage about your company?

1. Our company has professional team and professional production line.

2. Why should I choose your products?

2. Our products are high quality and low price.

3. The logo and the color can be customized?

3. Yes, we welcome you to sample custom.
